Wheels
Front Wheel 50-3
50
14. Using the hoist, raise the front of the
motorcycle until the front tire is slightly off the
floor.
15. Remove front axle and collect the front wheel.
Tool: 17mm hex bit socket. Torque: 40 lb-ft
(54 Nm).
16. Release the WSS sensor from the front wheel.
Installation
1. Installation is the reverse of the removal
procedure, but take note of the following
installation step.
2. When installing the WSS sensor, make sure
the alignment tab is positioned against the
bottom edge of the left front shock as shown.
