Zero SR/S User Manual

Body
Body 60-35
60
5. Remove bolts (x4) securing MBB to the tank
storage liner and collect washers (x4).
Tool: 6mm hex
CAUTION: Replace vibration-resistant
rubber isolator nuts if they are damaged or
worn.
Note: Do not over-tighten bolts.
6. Remove MBB.
7. Squeeze tabs to release OBDII connector from
tank storage liner.
8. Remove bolts (x2) securing USB power hub to
tank storage liner. Tool: T20. Torque: 2 lb-ft
(2.7 Nm).
9. Remove bolts (x2) securing storage liner to
storage liner plate. Tool: T27. Torque: 2.5 lb-ft
(3 Nm).
Note: During installation, do not snug storage
liner bolts until tank is installed.
10. Remove storage liner.
Installation
1. Installation is the reverse of the removal
procedure.

Zero SR/S Specifications

General

Category	Motorcycle
Peak Power	110 hp (82 kW)
Continuous Power	54 hp (40 kW)
Torque	140 ft-lb (190 Nm)
Range (City)	161 miles (259 km)
Range (with Power Tank)	200 miles (322 km)
Top Speed (Max)	124 mph (200 km/h)
Top Speed (Sustained)	110 mph (177 km/h)
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Motor	Z-Force 75-10
Battery	ZF14.4 Lithium-ion
Range (Highway)	82 miles (132 km) at 70 mph
Seat Height	787 mm (30.9 in)
Wheelbase	1, 450 mm (57.1 in)
Front Suspension	Showa 41 mm
Rear Suspension	Showa 40mm piston, piggy-back reservoir shock
Front Brake	Dual J-Juan asymmetric piston calipers, 320 x 5 mm discs
Rear Brake	J-Juan single piston floating caliper with 240mm disc
ABS	Bosch Gen 9
Charging Time (Standard)	4.5 hours
