Zero SR/S User Manual

2
Table of Contents
i
25 Charging System
Chargers
3KW Rapid Charger (Front) [Before 2022MY] ...............................................................25-1
3KW Rapid Charger (Front and Rear) [Before 2022MY]............................................... 25-7
6KW Charger [22MY Onwards] .....................................................................................25-14
Charge Inlet Harness......................................................................................................25-17
DC/DC Converter
DC/DC Converter ...........................................................................................................25-20
30 Motor and Drive System
Motor
Motor .................................................................................................................................30-1
Motor Stop Switch
Motor Stop Switch..........................................................................................................30-14
Throttle
Throttle (Without Heated Grips) ....................................................................................30-18
Throttle (With Heated Grips)..........................................................................................30-22
Controller
Motor Controller [Before 2022MY]................................................................................30-27
Motor Controller Carrier [Before 2022MY] ...................................................................30-39
Motor Controller with Heatsink [22MY Onwards] ........................................................30-42
Rear Sprocket
Rear Sprocket.................................................................................................................30-43
40 Suspension
Wheel Speed Sensor (WSS)
Wheel Speed Sensor (Front) ...........................................................................................40-1
Wheel Speed Sensor (Rear) ............................................................................................ 40-6
Front Suspension
Steering Stem .................................................................................................................40-11
Rear Suspension
Rear Shock .....................................................................................................................40-16
Swingarm ........................................................................................................................40-19
Doubler Plate Seals ........................................................................................................40-29
Replace Drive Belt..........................................................................................................40-35
Adjust Drive Belt .............................................................................................................40-39

Zero SR/S Specifications

General

Category	Motorcycle
Peak Power	110 hp (82 kW)
Continuous Power	54 hp (40 kW)
Torque	140 ft-lb (190 Nm)
Range (City)	161 miles (259 km)
Range (with Power Tank)	200 miles (322 km)
Top Speed (Max)	124 mph (200 km/h)
Top Speed (Sustained)	110 mph (177 km/h)
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Motor	Z-Force 75-10
Battery	ZF14.4 Lithium-ion
Range (Highway)	82 miles (132 km) at 70 mph
Seat Height	787 mm (30.9 in)
Wheelbase	1, 450 mm (57.1 in)
Front Suspension	Showa 41 mm
Rear Suspension	Showa 40mm piston, piggy-back reservoir shock
Front Brake	Dual J-Juan asymmetric piston calipers, 320 x 5 mm discs
Rear Brake	J-Juan single piston floating caliper with 240mm disc
ABS	Bosch Gen 9
Charging Time (Standard)	4.5 hours
