Zero SR/S User Manual

Charging System
Chargers 25-9
25
15. Disconnect harness connector.
16. Protect and secure charger port stand to the
side of motorcycle.
17. Release BMS signal harness connector
anchor from tank storage liner support. Tool:
Non-marring trim removal/pry tool.
18. To gain access to the left front bolt securing
tank storage liner support to motorcycle
frame, move the brake hoses toward the tank
storage liner support.
19. Remove left front bolt securing tank storage
liner support to motorcycle frame. Tool: T30.
Torque: 7.8 lb-ft (11 Nm).
20. Cut cable tie securing high voltage harness to
harness anchor on left side of storage liner
support.
Note: Replace cable tie during the installation
process.

Zero SR/S Specifications

General

Category	Motorcycle
Peak Power	110 hp (82 kW)
Continuous Power	54 hp (40 kW)
Torque	140 ft-lb (190 Nm)
Range (City)	161 miles (259 km)
Range (with Power Tank)	200 miles (322 km)
Top Speed (Max)	124 mph (200 km/h)
Top Speed (Sustained)	110 mph (177 km/h)
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Motor	Z-Force 75-10
Battery	ZF14.4 Lithium-ion
Range (Highway)	82 miles (132 km) at 70 mph
Seat Height	787 mm (30.9 in)
Wheelbase	1, 450 mm (57.1 in)
Front Suspension	Showa 41 mm
Rear Suspension	Showa 40mm piston, piggy-back reservoir shock
Front Brake	Dual J-Juan asymmetric piston calipers, 320 x 5 mm discs
Rear Brake	J-Juan single piston floating caliper with 240mm disc
ABS	Bosch Gen 9
Charging Time (Standard)	4.5 hours
