208
MAIN TECHNICAL PARAMETERS
POWER
Tractor type Z 90 Z 100 Z 110 Z 120
Engine type 1206 1006 1306 1406
PTO power (kW±2%)
- at the nominal engine speed and engaged 1000 rpm of the
PTO
Engine in the running-in stage (until 100 hours) 50 55 62.5 69.5
Engine after the running-in stage (from 100 hours on) 52.5 58 65.5 73
LIFTING FORCE OF THE THREE-POINT HITCH
Tractor type Z 90 Z 100 Z 110 Z 120
Engine type 1206 1006 1306 1406
Lifting force at the end of the lower draw-bars of the rear three-
point hitch in the whole lifting range at the maximum usable
pressure with 2 outer cylinders
- cylinder 75mm in diameter (kN) 38
Lifting force at the end of the lower draw-bars of the front
three-point hitch in the whole lifting range at the maximum us-
able pressure (kN) 23
