40
ACQUAINTANCE WITH THE TRACTOR
PPw+11NH127a
CONTROL PANEL ON THE CAB RIGHT PILLER
1. rear PTO shaft switch
2. front shaft switch
3. two-position switch of the windscreen wiper and washer
4. rear window wiper switch
5. switch of front working lights on cab roof
6. switch of rear working lights on cab roof
7. *rear mirrors heating switch
8. *rear window defroster switch
9. delay of the rear PTO shaft. 3 modes according to the tool connected:
5S – use this mode to start PTO shaft connected light machines with low en-
gine power take-off such as tedding machines
3S – use this mode to start PTO shaft connected light machines with middle
engine power take-off such as disc reaping machines
1S – use this mode to start PTO shaft connected heavy machines with high en-
gine power take-off such as feeding machines, drum reaping machines, and
field and forest cultivators.
