Programming
90 025-9227S
♦ To configure Custom Calls
1. Click Edit, System Configuration, Edit Custom Calls.
If the Edit Custom Calls menu item is disabled, you must first assign a leading
digit to a custom paging format (see To assign and configure a paging format for a
leading digit on page 88).
2. Type in a custom Call Number between 1 and 255 and press Enter. Alternatively,
you can select a call number by using the Up and Down arrow controls or the Next
and Prev buttons.
Choose a Call Number based on the number to key in. For example, if the “Custom
Call” paging format has been assigned to leading digit “C” and you configure Call
Number “11”, then keying “C11” on the Model 4010 paging/DTMF keypad would
add the custom call to the paging stack.
3. If you are configuring a call number that wasn’t previously defined, click Define to
make the Tone Settings editable. (If the call number was previously defined, the
Tone Settings are already editable.)
4. Enter the Frequency and Duration parameters for each tone, the Tone Gap
Duration (duration between tones 1 and 2), and the Tal k Tim e. For an explanation
of Talk Time, see Step 4 on 88.
5. If you have additional Call Numbers to configure, repeat this procedure. If you are
finished, click OK.
♦ To delete custom calls
1. To delete all custom calls, click Delete All Custom Calls.
2. To delete a specific custom call:
a. Select the Call Number to be deleted.
b. Click Delete.
Input/Output Configuration
The main board of the Model 4010 is equipped with eight inputs and outputs. These inputs
and outputs can be used as auxiliary inputs and outputs, or as spare inputs and outputs. All
inputs on the board must be one or the other (auxiliary or spare). All outputs must be one
Tip The defined buttons jump to the next or previous defined call
numbers only, thus skipping undefined call numbers.
Tip The Revert button will restore the settings of the current call
number only. The settings for other call numbers are not affected.
