Ziehm Imaging, Inc. QUANTUM User Manual

Section 12.0
MAN 06–0017H
ZIEHM QUANTUM User’s Manual Page 182 of 220
Power
120 VAC 60Hz Option: 230 VAC 60Hz
Direct radiography: 40–110 kV 40–110 kV
Tube Current 2 mA min/ 20mA max. 2 mA min. /20 mA max.
mAs Range .4 mAs min./100 mAs max .4 mAs min. /100 mAs max.
Fluoroscopy: 40–110 kV 40–110 kV
0.1–6 mA 0.1–6 mA
−Pulsed mode: Pulse Max 3F/s Pulse Max 3 F/s
Digital radiography 40–110 kV 40–110 kV
(snapshot): 0.2 mA min./20 mA max. 0.2 mA min./20 mA max.
Operating frequency: 20 kHz 20 kHz
Required residual current
I
N
≥ 16 A, I
AN
= 30 mA I
N
≥ 20 A, I
AN
= 30 mA
Line resistance
<
.6 Ohms < .6 Ohms
Max. operating data
Fluoroscopy Generator 110 kV / 6 mA 110 kV / 6 mA
80 kV / 6 mA 80 kV / 6 mA
Direct radiography: 110 kV / 8 mA 110 kV / 8 mA
80 kV / 8 mA 80 kV / 8 mA
Radiography: 110 kV / 18 mA 110 kV / 20 mA
80 kV / 18 mA 80 kV / 20 mA
Max. power output
Fluoroscopy: 660 W (110 kV / 6 mA) 660 W (110 kV / 6 mA)
Direct radiography: 880W (110 kV / 8 mA) 880 W (110 kV / 8 mA)
Direct radiography: 1980 W (110 kV / 18 mA) 2200 W (110 kV / 20 mA)
Nominal electric power
2000 W at 100 kV / 20 mA / 0.1 s
X -ray tube
Dual-focus stationary-anode tube
Focal spot nominal size
Nagel
0.6 acc. to IEC Small
1.5 acc to IEC Large
Toshiba
0.5 acc. to IEC Small
1.5 acc to IEC Large
Total filtration
≥ 39 mm Al @ 110kV
Image Intensifier Tube
Input screen: Cesium iodide
