Section 12.0
MAN 06–0017H
ZIEHM QUANTUM User’s Manual Page 184 of 220
Manufacturer: Ziehm GmbH
Dose Rate Control
kV - mA are constant pairs and is set
by the factory.
12.4 MECHANICS
Weight Monitors ( Pair)
With 18.1" flat-screen monitors: approx. 12.6 kg
18.1" flat-screen monitors
Screen size:
Resolution:
460 mm (18.1")
1280 × 1024 / 60 Hz
During storage Conditions
Temperature: –10°C to +60°C
Relative air humidity: 95% max.
During operation
Environmental
Temperature: +15°C to +35°C
Relative air humidity: 75% max
X-Ray Tube Focal Spot and Reference Axis 30” C-profile opening
