Zoom F1 User Manual

Inserting microSD cards
1.
Turn the power o and then open the microSD card slot cover.
2.
Insert the microSD card into the card slot.
To remove a microSD card, gently push it further into the slot and then pull it out.
3.
Close the microSD card slot cover.
NOTE
• Always make certain that the power is o when inserting or removing a microSD card. Inserting or removing a
card while the power is on could result in data loss.
• When inserting a microSD card, be sure to insert the correct end with the top side up as shown.
• Recording and playback are not possible when a microSD card is not loaded in the
.
• To format a microSD card, see "Formatting microSD cards".
11

Zoom F1 Specifications

General

Type	Field Recorder
Audio Formats	WAV, MP3
Max Sample Rate/Resolution	96 kHz / 24-Bit
Power	2 x AAA Batteries, USB Bus Power
Battery Life	Up to 10 hours
Simultaneous Recording Tracks	2
Built-In Microphone	No
Input Channels	2
Output Channels	1
USB	1 x Micro-USB
Recording Media	microSD/microSDHC cards (up to 32 GB)
Dimensions	64 x 79.8 x 34 mm
Display	Monochrome LCD
Line Input	1 x 1/8" (3.5 mm) TRS
Headphone Output	1 x 1/8" / 3.5 mm TRS
Microphone Input	1 x 1/8" (3.5 mm) TRS
