Zoom F1 User Manual

Using as an audio interface
input signals can be input directly to a computer, iOS device or other equipment, and playback signals on a
computer, iOS device or other equipment can be output from the
.
1.
Press or on the USB screen to select "Audio I/F", and press .
2.
Use or to select the type of device, and press .
NOTE
After selecting "iOS", turn the
power on, follow the instructions on screen, and disconnect the cable once.
Then, select "iOS" again and reconnect the cable.
3.
After selecting PC/Mac, use or to select the power source, and press .
The following power sources can be selected.
44

Zoom F1 Specifications

General

Type	Field Recorder
Audio Formats	WAV, MP3
Max Sample Rate/Resolution	96 kHz / 24-Bit
Power	2 x AAA Batteries, USB Bus Power
Battery Life	Up to 10 hours
Simultaneous Recording Tracks	2
Built-In Microphone	No
Input Channels	2
Output Channels	1
USB	1 x Micro-USB
Recording Media	microSD/microSDHC cards (up to 32 GB)
Dimensions	64 x 79.8 x 34 mm
Display	Monochrome LCD
Line Input	1 x 1/8" (3.5 mm) TRS
Headphone Output	1 x 1/8" / 3.5 mm TRS
Microphone Input	1 x 1/8" (3.5 mm) TRS
