Zoom F1 User Manual

Setting value Explanation
Bus Power Power is supplied from the computer through the USB cable.
Battery
Power is supplied by the batteries in the
. Select this when connected to a com-
puter that has low USB bus power supply capability.
NOTE
When "iOS" is selected, power is supplied by the batteries in the
. This screen will not be shown.
4.
Monitor playback signals from the computer or iOS device.
HINT
When connected to a Windows computer, you can use a dedicated driver for low-latency monitoring.
Download the driver from the ZOOM website (www.zoom.co.jp).
5.
To disconnect, while pressing , press .
6.
Use and to select "Exit", and press .
7.
Disconnect the USB cable from the and the computer or iOS device.
45

Zoom F1 Specifications

General

Type	Field Recorder
Audio Formats	WAV, MP3
Max Sample Rate/Resolution	96 kHz / 24-Bit
Power	2 x AAA Batteries, USB Bus Power
Battery Life	Up to 10 hours
Simultaneous Recording Tracks	2
Built-In Microphone	No
Input Channels	2
Output Channels	1
USB	1 x Micro-USB
Recording Media	microSD/microSDHC cards (up to 32 GB)
Dimensions	64 x 79.8 x 34 mm
Display	Monochrome LCD
Line Input	1 x 1/8" (3.5 mm) TRS
Headphone Output	1 x 1/8" / 3.5 mm TRS
Microphone Input	1 x 1/8" (3.5 mm) TRS
