Reference [Mixer]
ZOOM HD8/HD16
86
• CHORUS/DELAY group
Pad 5 (CHORUS/DELAY)
• REVERB group
Pad 6 (REVERB)
• MASTER FADER group
[MASTER] status key
When a group is enabled, the respective key/pad is lit, and
when the group is disabled, the key/pad goes out.
HINT
• The on/off setting for the TRACK PARAMETER group can be
made for each track individually.
• The on/off setting for the drum track and bass track can be
made together with the [RHYTHM] status key.
•You can use the cursor up/down keys to enable or disable all
groups together except for the MASTER FADER group.
4. When the setting is complete, repeatedly
press the [EXIT] key.
The main screen returns.
The settings made here are stored as part of the project.

Zoom HD16 Specifications

General

Tracks	16
Simultaneous Recording Tracks	8
Phantom Power	Yes
Built-in Effects	Yes
USB	Yes
Simultaneous Playback Tracks	16
Sampling Frequency	44.1kHz
A/D Conversion	24-bit
D/A Conversion	24-bit
Recording Format	WAV
Built-in Rhythm Patterns	Yes
USB Audio Interface	Yes
SD Card Slot	No
Input Channels	8
Output Channels	2
LCD Display	Yes
Type	Multitrack Recorder
Effects	Yes
Headphone Output	Yes
Inputs	8 XLR/TRS combo inputs
