30 CHAPTER 2: LOGGING INTO AN ETHERNET SWITCH
Network diagram
Figure 6 Network diagram for AUX user interface configuration (with the authentication
mode being none)
Configuration procedure
# Enter system view.
<4210> system-view
# Enter AUX user interface view.
[4210] user-interface aux 0
# Specify not to authenticate users logging in through the Console port.
[4210-ui-aux0] authentication-mode none
# Specify commands of level 2 are available to users logging into the AUX user
interface.
[4210-ui-aux0] user privilege level 2
# Set the baud rate of the Console port to 19,200 bps.
[4210-ui-aux0] speed 19200
# Set the maximum number of lines the screen can contain to 30.
[4210-ui-aux0] screen-length 30
# Set the maximum number of commands the history command buffer can store
to 20.
[4210-ui-aux0] history-command max-size 20
# Set the timeout time of the AUX user interface to 6 minutes.
