POE PROFILE CONFIGURATION
Introduction to PoE
Profile
On a large-sized network or a network with mobile users, to help network
administrators monitor the switch’s PoE features , the Switch 4210 provides the
PoE profile features. A PoE profile is a set of PoE configurations, including multiple
PoE features.
Features of PoE profile:
■ Various PoE profiles can be created. PoE policy configurations applicable to
different user groups are stored in the corresponding PoE profiles. These PoE
profiles can be applied to the ports used by the corresponding user groups.
■ When users connect a PD to a PoE-profile-enabled port, the PoE configurations
in the PoE profile will be enabled on the port.
PoE Profile
Configuration
Configuring PoE Profile
Tab le 270 Configure PoE profile
Operation Command Description
Enter system view system-view -
Create a PoE profile and enter PoE profile view poe-profile
profilename
Required
If the PoE file is
created, you will
enter PoE profile
view directly
through the
command.
Configure the
relevant
features in PoE
profile
Enable the PoE feature on a
port
poe enable Required
Disabled by default.
Configure PoE mode for
Ethernet ports
poe mode { signal |
spare }
Optional
signal by default.
Configure the PoE priority
for Ethernet ports
poe priority { critical |
high | low }
Optional
low by default.
Configure the maximum
power for Ethernet ports
poe max-power
max-power
Optional
15,400 mW by
default.
Quit system view quit -
