318 CHAPTER 30: CLUSTER
Figure 99 A cluster implementation
Switch Clustering V2 has the following advantages:
■ It eases the configuration and management of multiple switches: You just need
to configure a public IP address for the management device instead of for all
the devices in the cluster; and then you can configure and manage all the
member devices through the management device without the need to log onto
them one by one.
■ It provides the topology discovery and display function, which assists in
monitoring and maintaining the network.
■ It allows you to configure and upgrade multiple switches at the same time.
■ It enables you to manage your remotely devices conveniently regardless of
network topology and physical distance.
■ It saves IP address resource.
Roles in a Cluster The switches in a cluster play different roles according to their functions and
status. You can specify the role a switch plays. A switch in a cluster can also switch
to other roles under specific conditions.
As mentioned above, the three cluster roles are management device, member
device, and candidate device.
Network Mangerment Station
69 .110 .1.100
Network
Cluster
69.110.1.1
Mangerment Device
Member Device
Member Device
Member Device
