Logging in through the Console Port 35
Note that if you configure to authenticate the users in the scheme mode, the
command level available to users logging into a switch depends on the command
level specified in the service-type terminal [ level level ] command.
Configure the
Console port
Set the
baud rate
speed speed-value Optional
The default baud rate of the
AUX port (also the Console
port) is 9,600 bps.
Set the
check
mode
parity { even | none | odd
}
Optional
By default, the check mode
of a Console port is set to
none, that is, no check bit.
Set the
stop bits
stopbits { 1 | 1.5 | 2 } Optional
The default stop bits of a
Console port is 1.
Set the
data bits
databits { 7 | 8 } Optional
The default data bits of a
Console port is 8.
Configure the command level
available to users logging into the
user interface
user privilege level level Optional
By default, commands of
level 3 are available to users
logging into the AUX user
interface.
Make terminal services available
to the user interface
shell Optional
By default, terminal services
are available in all user
interfaces.
Set the maximum number of lines
the screen can contain
screen-length
screen-length
Optional
By default, the screen can
contain up to 24 lines.
You can use the
screen-length 0 command
to disable the function to
display information in pages.
Set history command buffer size history-command
max-size value
Optional
The default history command
buffer size is 10. That is, a
history command buffer can
store up to 10 commands by
default.
Set the timeout time for the user
interface
idle-timeout minutes [
seconds ]
Optional
The default timeout time of a
user interface is 10 minutes.
With the timeout time being
10 minutes, the connection
to a user interface is
terminated if no operation is
performed in the user
interface within 10 minutes.
You can use the
idle-timeout 0 command to
disable the timeout function.
Table 16 Console port login configuration with the authentication mode being scheme
Operation Command Description
