BFB-3000 Set Up and Operations Manual
Document No: D100253 17
6.4 Power up
 Connect the power supply from the control panel into the power socket shown in
Figure 1. Turn the supply on. Turn the control box on using the power switch shown
in Figure 1.
Figure 1: Control panel
Table 1: Buttons used for navigation
Button
Screen Navigation
+Y
Up
-Y
Down
+X
Enter
Esc
Escape
+Z
Extruder selection up (see ‘Extruder control’, page 36)
-Z
Extruder selection down (in ‘Extruder control’, page 36)
Power
socket
+Z, -Z, Escape buttons
Screen
+Y, -Y, -X,
+X/Enter buttons
buttons
Power switch
Power
indicator
SD card
indicator
SD card
