3D Systems BFB-3000 User Manual

BFB-3000 Set Up and Operations Manual
Document No: D100253 64
9.5.4 Handling a ground-out filament
If a pressure bearing is poorly assembled, or the nozzle suffers from a blockage (e.g.
printing too close to the bed), the back of the filament may be ground out by the extruder
drive shaft. The drive shaft will then be unable to push the filament down into the nozzle,
preventing the extruder from extruding. This is normally indicated by a fast build-up of
plastic dust around the pressure bearing.
If the nozzle is not
extruding, a build up
of plastic dust can
indicate a ground out
filament.
Remove
pressure
bearing

3D Systems BFB-3000 Specifications

General

Brand	3D Systems
Model	BFB-3000
Category	3D Printers
Language	English
