3xLogic VISIX Gen III Series User Manual

Pg. 10
www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com
Browser Interface -
Main Screen - Cont'd
5
PTZ, Presets, Tours, Speaker / Audio Controls and Alarm controls are model-dependent and will only be accessible on applicable
models.
6
Motion -This indicator shows the Motion event status.
Event Alert Icon ( ) appears if ‘Motion Detection’ is activated. Motion record is enabled by default.
7
Camera Time - Display the camera system's time.
PTZ Control - If using a PTZ-enabled model camera, PTZ motion can be controlled from this interface.
Home Position - Click this button to reset the PTZ to default home position.
Preset - You can add PTZ presets by clicking the + button when the camera is at the desired PTZ location. Up to 255 presets can
be saved.
Preset Tour - You can add a Preset Tour by clicking the + button and and adding the desired PTZ presets you would like the
camera to tour. Up to 10 Tours can be saved.
Delay and Speed can be set from 1 to 10.
Speaker Control - Enable/Disable the Audio stream received from the camera. The system volume can also be set. Audio controls
are only available for applicable models.
Alarm Input - Alarm input indicator. If an alarm is triggered, the corresponding input's color will be changed to red from gray.
Relay Out - Using these controls, you can read the status of the Relay Out switch and also set or reset it manually.
2
3
4
5
6
7
1
