3xLogic VISIX Gen III Series - Camera Backlight Settings

Pg. 25
www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com
This is a feature used for problematic light conditions where the contrast from light to dark areas is very high.
1
WDR (Wide Dynamic Range) - The WDR function can be enabled or disabled.
2
WDR Level - Set the WDR level.
3
BLC (Back Light Compensation) - The BLC function can only be set when WDR is off.
4
Click Save to save the current settings.
Click 'Cancel' to return to the previous settings.
Click 'Default' to return settings to the factory defaults.
Setup - Camera Setup
Camera Backlight Settings
1
2
3
4
