3xLogic VISIX Gen III Series User Manual

Pg. 42
www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com
1
Relay Output - Select the Relay output to trigger.
The number of relay outputs depends on the camera model.
2
Mode - Select monostable / bistable for relay mode.
3
Idle State - Select whether the contact is normally opened or is closed.
4
Duration - The relay will remain trigger during the set time.
If bistable mode is selected, this function is activated
5
Click Apply to save the new settings.
Setup - Trigger Action Setup
Relay Out Configuration
1
3
4
2
5
