3xLogic VISIX Gen III Series - Event Rules Configuration

Pg. 44
www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com
1
Activation - The Event Rules function can be enabled or disabled here.
2
Name - Define the Event rule name.
3
Event - Select the event type. Types include motion detection, network disconnection, illegal login detected, temperature
critical, schedule,sensor detection.
Click 'Cancel' to return to the previous setting.
4
Schedule - Set an activation time. The event can only occur during the stated time period. Always / Manual Time available.
Manual mode will require the custom creation of a schedule.
5
Week / Time - When manual is selected, you need to define a
Start time
and
End time
followed by selecting
Days
. The setup
schedule is repeated every week.
6
Rules - Select the action rule defined in the Trigger Action-Action rule menu.
7
Click Save to save the current settings.
Click 'Cancel' to return to the previous setting.
Setup - Event Setup
Event Rules Configuration
3
6
4
7
1
2
5
