Managing the Radio | 169
Aprisa SR+ User Manual 1.11.1
Ethernet > Port Setup
This page provides the setup for the Ethernet ports settings.
ETHERNET PORT SETTINGS
Note: This screen is dependent on the Data Port product option purchased (see ‘Data Interface Ports’ on
page 401). The Data Port product option shown is a 2E2S – two Ethernet ports and two Serial ports
Mode
This parameter controls the Ethernet traffic flow. The default setting is Standard.
Option
Function
Standard
Enables Ethernet data communication over the radio link but
Ethernet traffic is not switched locally between the two
Ethernet ports.
Switch
Ethernet traffic is switched locally between the two
Ethernet ports and communicated over the radio link
Disabled
Disables all Ethernet data communications.
