188 | Managing the Radio
Aprisa SR+ User Manual 1.11.1
PVID
This parameter sets the PVID (port VLAN ID) for each of the terminal servers on the radio.
Protocol Conversion
This parameter defines the mode of operation of the terminal server connection. The default setting is
None.
Option
Function
None
No terminal server Protocol Conversion
Modbus TCP to Modbus RTU
The radio provides a gateway between Modbus TCP to
Modbus RTU.
Modbus TCP to Modbus ASCII
The radio provides a gateway between Modbus TCP to
Modbus ASCII.
Local Address
This parameter sets the Terminal Server local IP address.
Bridge Mode
The local IP address can be the same as the radio's configured IP address or the Virtual IP address for
protected stations. If it is not the above, then it must be an IP address from a network different from the
radio's network.
Note that the Terminal Server local IP address settings can be the same for other terminal servers in the
radio.
Router Mode
The local IP address must be the same as any one of the radio's configured port IP addresses or the Virtual
IP address for protected stations.
Gateway Router Mode
The local IP address must be the same as the radio's configured IP address or the Virtual IP address for
protected stations.
Local Port
This parameter sets the TCP or UDP port number of the local serial port.
The valid port number range is less than or equal to 49151 but with exclusions of 0, 20, 21, 23, 80, 161, 162,
443, 5445, 6445, 9930 or 9931. The default setting is 20000.
The user is responsible for ensuring that there is no conflict on the network.
Remote Address
This parameter sets the IP address of the server connected to the radio Ethernet port. When the remote
address / port is configured as 0.0.0.0/0, each outgoing UDP packet will be sent to the source address of
the last received UDP packet.
Remote Port
This parameter sets the TCP or UDP port number of the server connected to the radio Ethernet port. The
default setting is 0.
