Managing the Radio | 215
Aprisa SR+ User Manual 1.11.1
PRIORITY CRITERIA
Priority Type
Set the layer 2 Ethernet or layer 3 IP packet header priority type fields in the selected profile classification
rules.
Priority Type
Description
None
Do not use any layer 2 / 3 Ethernet or IP header
priority fields in the selected profile classification
rules.
PCP
Use the layer 2 Ethernet header priority field of
PCP (Priority Code Point) VLAN priority bits (per
IEEE 802.1p/q) in the selected profile
classification rules.
DSCP
Use the layer 3 IP header TOS field used as DSCP
(Differentiated Services Code Point per RFC 2474
and RFC 2475) priority bit in the selected profile
classification rules.
PCP / DSCP Range
As per the ‘priority type’ selection, this parameter sets the PCP priority value/s or DSCP priority value/s
fields in the selected profile classification rule. The value can be set to a single priority or a single range
(no multiple ranges are allowed), for example, the PCP selected priority value can be 7 or a range of priority
values like 4-7.
The following table shows the layer 2 packet VLAN tag header PCP priority field values
PCP Value
(Decimal)
PCP Priority
Priority Level
7
Priority [7]
Highest
6
Priority [6]
5
Priority [5]
4
Priority [4]
3
Priority [3]
2
Priority [2]
1
Priority [1]
0
Priority [0]
Lowest
