Dismantling and fitting
Page 74 /
121
© Copyright 2017 ABB. All rights reserved.
HZTL4031_EN
Revision E
January 2017
Identification of the assembly devices
Not all assembly devices are marked with a part number. Identification is guaranteed by the
tool list. This list is enclosed in the toolbox.
WARNING
Servicing the assembly devices
Assembly devices must be checked for damage before and after use.
 Visually inspect for corrosion, cracks, deformation and wear.
 Damaged assembly devices must no longer be used and must be re-
placed.
Customer spare part set
Before starting operations, make sure the required customer spare part sets are available.
 See chapter Spare parts [➙ 115].
Oil orifice
 When disassembling the turbocharger, an oil orifice fitted in the oil inlet must not be re-
moved (see also chapter Removing the cartridge group [➙ 87]).
Tightening torques for components of the turbocharger
The specified tightening torques of the screw fittings must be observed (Table of tightening
torques [➙ 105]).
Tightening torques for assembly devices
Unless described otherwise, the screws and nuts of the assembly devices supplied by ABB
must be tightened so they rest firmly against the surface.
