Operation Manual / 4 Product description / A130-M.. - A145-M..
Page 106 /
© Copyright 2017 ABB. All rights reserved.
Figure 57: Tightening torques for insulation
The following tightening torques must be observed for the specified screw connections:
16a /
16b
1)
- - M10
40 Nm
M10
40 Nm
M12
65 Nm
M12
65 Nm
16b
2)
- - M8
20 Nm
M8
20 Nm
M10
40 Nm
M10
40 Nm
10 Nm
10 Nm
10 Nm
10 Nm
19 - - M8
25 Nm
M8
25 Nm
M8
25 Nm
M8
25 Nm
45 Nm
45 Nm
45 Nm
45 Nm
Table 47: Tightening torques for insulation
1)
Tightening torque for attaching the insulation with integrated burst protection at the turbine
casing
2)
Tightening torque for attaching the insulation to the burst protection.
