Operation Manual / 4 Product description / A130-M.. - A145-M..
Page 105 /
© Copyright 2017 ABB. All rights reserved.
8.20 Table of tightening torques
Figure 56: Tightening torques
The following tightening torques must be observed for the specified screw connections:
60 Nm
60 Nm
60 Nm
60 Nm
04 79041 M6
8 Nm
M6
8 Nm
M6
8 Nm
M6
8 Nm
25 Nm
45 Nm
75 Nm
75 Nm
09 51009 M8
20 Nm
M10
40 Nm
M12
65 Nm
M12
65 Nm
35 Nm
70 Nm
105 Nm
170 Nm
15 86505 M12 x 1.5
15 Nm
M12 x 1.5
15 Nm
M12 x 1.5
15 Nm
M12 x 1.5
15 Nm
40 Nm
40 Nm
65 Nm
65 Nm
Table 46: Tightening torques
*) With the variant "insulation with integrated burst protection", this position can be ignored.
