Communication with M-Bus
A43/A44 202 2CMC48001M0201
User Manual Revision: C
Byte No.
Size
Value
Description
48
1
xx
VIFE status
49-52
4
xxxxxxxx
Active power, L2
53
1
04
DIF size, 32 bit integer
54
1
A9
VIF for units W with resolution 0,01W
55
1
FF
VIFE next byte is manufacturer specific
56
1
83
VIFE L3
57
1
xx
VIFE status
58-61
4
xxxxxxxx
Active power, L3
62
1
84
DIF size, 32 bit integer
63
1
80
DIFE (Unit = 0)
64
1
40
DIFE (Unit = 1, => xx10 (2))
65
1
A9
VIF for units var with resolution 0,01var
66
1
xx
VIFE status
67-70
4
xxxxxxxx
Reactive power, Total
71
1
84
DIF size, 32 bit integer
72
1
80
DIFE (Unit = 0)
73
1
40
DIFE (Unit = 1, => xx10 (2))
74
1
A9
VIF for units var with resolution 0,01var
75
1
FF
VIFE next byte is manufacturer specific
76
1
81
VIFE L1
77
1
xx
VIFE status
78-81
4
xxxxxxxx
Reactive power, L1
82
1
84
DIF size, 32 bit integer
83
1
80
DIFE (Unit = 0)
84
1
40
DIFE (Unit = 1, => xx10 (2))
85
1
A9
VIF for units var with resolution 0,01var
86
1
FF
VIFE next byte is manufacturer specific
87
1
82
VIFE L2
88
1
xx
VIFE status
89-92
4
xxxxxxxx
Reactive power, L2
93
1
84
DIF size, 32 bit integer
94
1
80
DIFE (Unit = 0)
95
1
40
DIFE (Unit = 1, => xx10 (2))
96
1
A9
VIF for units var with resolution 0,01var
97
1
FF
VIFE next byte is manufacturer specific
98
1
83
VIFE L3
99
1
xx
VIFE status
100-103
4
xxxxxxxx
Reactive power, L3
104
1
84
DIF size, 32 bit integer
105
1
80
DIFE (Unit = 0)
106
1
80
DIFE (Unit = 0)
