ABB A43

Communication with M-Bus
2CMC48001M0201 203 A43/A44
Revision: C User Manual
Byte No.
Size
Value
Description
107
1
40
DIFE (Unit = 1, => x100 (4))
108
1
A9
VIF for units VA with resolution 0,01VA
109
1
xx
VIFE status
110-113
4
xxxxxxxx
Apparent power, Total
114
1
84
DIF size, 32 bit integer
115
1
80
DIFE (Unit = 0)
116
1
80
DIFE (Unit = 0)
117
1
40
DIFE (Unit = 1, => x100 (4))
118
1
A9
VIF for units VA with resolution 0,01VA
119
1
FF
VIFE next byte is manufacturer specific
120
1
81
VIFE L1
121
1
xx
VIFE status
122-125
4
xxxxxxxx
Apparent power, L1
126
1
84
DIF size, 32 bit integer
127
1
80
DIFE (Unit = 0)
128
1
80
DIFE (Unit = 0)
129
1
40
DIFE (Unit = 1, => x100 (4))
130
1
A9
VIF for units VA with resolution 0,01VA
131
1
FF
VIFE next byte is manufacturer specific
132
1
82
VIFE L2
133
1
xx
VIFE status
134-137
4
xxxxxxxx
Apparent power, L2
138
1
84
DIF size, 32 bit integer
139
1
80
DIFE (Unit = 0)
140
1
80
DIFE (Unit = 0)
141
1
40
DIFE (Unit = 1, => x100 (4))
142
1
A9
VIF for units VA with resolution 0,01VA
143
1
FF
VIFE next byte is manufacturer specific
144
1
83
VIFE L3
145
1
xx
VIFE status
146-149
4
xxxxxxxx
Apparent power, L3
150
1
04
DIF size, 32 bit integer
151
1
FD
VIF extension of VIF-codes
152
1
C8
VIFE for units V with resolution 0,1V
153
1
FF
VIFE next byte is manufacturer specific
154
1
81
VIFE L1
155
1
xx
VIFE status
156-159
4
xxxxxxxx
Voltage L1 - N
160
1
04
DIF size, 32 bit integer
161
1
FD
VIF extension of VIF-codes
162
1
C8
VIFE for units V with resolution 0,1V
