ABB A43

Communication with M-Bus
2CMC48001M0201 209 A43/A44
Revision: C User Manual
Byte No.
Size
Value
Description
174
1
84
VIF for units kvarh with resolution 0,01kvarh
175
1
xx
VIFE status
176-181
6
xxxxxxxxxxxx
Reactive imported energy, Tariff 3
182
1
8E
DIF size, 12 digit BCD
183
1
80
DIFE,
184
1
50
DIFE, tariff 4, unit 2
185
1
84
VIF for units kvarh with resolution 0,01kvarh
186
1
xx
VIFE status
187-192
6
xxxxxxxxxxxx
Reactive imported energy, Tariff 4
193
1
8E
DIF size, 12 digit BCD
194
1
C0
DIFE, unit bit 0
195
1
40
DIFE, unit bit 1, unit bit0-1-> unit 3
196
1
84
VIF for units kvarh with resolution 0,01kvarh
197
1
xx
VIFE status
198-203
6
xxxxxxxxxxxx
Reactive exported energy, Total
204
1
8E
DIF size, 12 digit BCD
205
1
D0
DIFE, tariff 1, unit bit 0
206
1
40
DIFE, unit bit 1, unit bit 0-1-> unit 3
207
1
84
VIF for units kvarh with resolution 0,01kvarh
208
1
xx
VIFE status
209-214
6
xxxxxxxxxxxx
Reactive exported energy, Tariff 1
215
1
8E
DIF size, 12 digit BCD
216
1
E0
DIFE, tariff 2, unit bit 0
217
1
40
DIFE, unit bit 1, unit bit 0-1-> unit 3
218
1
84
VIF for units kvarh with resolution 0,01kvarh
219
1
xx
VIFE status
220-225
6
xxxxxxxxxxxx
Reactive exported energy, Tariff 2
226
1
8E
DIF size, 12 digit BCD
227
1
F0
DIFE, tariff 3, unit bit 0
228
1
40
DIFE, unit bit 1, unit bit 0-1-> unit 3
229
1
84
VIF for units kvarh with resolution 0,01kvarh
230
1
xx
VIFE status
231-236
6
xxxxxxxxxxxx
Reactive exported energy, Tariff 3
237
1
8E
DIF size, 12 digit BCD
238
1
C0
DIFE, unit bit 0
239
1
50
DIFE, tariff 4, unit bit 1, unit bit 0-1-> unit 3
240
1
84
VIF for units kvarh with resolution 0,01kvarh
241
1
xx
VIFE status
242-247
6
xxxxxxxxxxxx
Reactive exported energy, Tariff 4
248
1
01
DIF size, 8 bit integer
249
1
FF
VIF next byte is manufacturer specific
