ABB A43

Communication with M-Bus
2CMC48001M0201 217 A43/A44
Revision: C User Manual
Byte No.
Size
Value
Description
17
1
xx
Status
18-19
2
0000
Signature (0000 = no encryption)
20
1
0E
DIF size, 12 digit BCD
21
1
84
VIF for units kWh with resolution 0,01kWh
22
1
FF
VIFE next byte is manufacturer specific
23
1
81
VIFE L1
24
1
xx
VIFE status
25-30
6
xxxxxxxxxxxx
Active imported energy, L1
31
1
0E
DIF size, 12 digit BCD
32
1
84
VIF for units kWh with resolution 0,01kWh
33
1
FF
VIFE next byte is manufacturer specific
34
1
82
VIFE L2
35
1
xx
VIFE status
36-41
6
xxxxxxxxxxxx
Active imported energy, L2
42
1
0E
DIF size, 12 digit BCD
43
1
84
VIF for units kWh with resolution 0,01kWh
44
1
FF
VIFE next byte is manufacturer specific
45
1
83
VIFE L3
46
1
xx
VIFE status
47-52
6
xxxxxxxxxxxx
Active imported energy, L3
53
1
8E
DIF size, 12 digit BCD
54
1
80
DIFE
55
1
40
DIFE, Unit 2
56
1
84
VIF for units kvarh with resolution 0,01 kvarh
57
1
FF
VIFE next byte is manufacturer specific
58
1
81
VIFE L1
59
1
xx
VIFE status
60-65
6
xxxxxxxxxxxx
Reactive imported energy, L1
66
1
8E
DIF size, 12 digit BCD
67
1
80
DIFE
68
1
40
DIFE, Unit 2
69
1
84
VIF for units kvarh with resolution 0,01 kvarh
70
1
FF
VIFE next byte is manufacturer specific
71
1
82
VIFE L2
72
1
xx
VIFE status
73-78
6
xxxxxxxxxxxx
Reactive imported energy, L2
79
1
8E
DIF size, 12 digit BCD
80
1
80
DIFE
81
1
40
DIFE, Unit 2
82
1
84
VIF for units kvarh with resolution 0,01 kvarh
83
1
FF
VIFE next byte is manufacturer specific
