Communication with M-Bus
A43/A44 218 2CMC48001M0201
User Manual Revision: C
Byte No.
Size
Value
Description
84
1
83
VIFE L3
85
1
xx
VIFE status
86-91
6
xxxxxxxxxxxx
Reactive imported energy, L3
92
1
8E
DIF size, 12 digit BCD
93
1
80
DIFE
94
1
80
DIFE
95
1
40
DIFE, Unit 4
96
1
84
VIF for unit kVAh with resolution 0,01kVAh
97
1
FF
VIFE next byte is manufacturer specific
98
1
81
VIFE L1
99
1
xx
VIFE status
100-105
6
xxxxxxxxxxxx
Apparent imported energy, L1
106
1
8E
DIF size, 12 digit BCD
107
1
80
DIFE
108
1
80
DIFE
109
1
40
DIFE, Unit 4
110
1
84
VIF for unit kVAh with resolution 0,01kVAh
111
1
FF
VIFE next byte is manufacturer specific
112
1
82
VIFE L2
113
1
xx
VIFE status
114-119
6
xxxxxxxxxxxx
Apparent imported energy, L2
120
1
8E
DIF size, 12 digit BCD
121
1
80
DIFE
122
1
80
DIFE
123
1
40
DIFE, Unit 4
124
1
84
VIF for unit kVAh with resolution 0,01kVAh
125
1
FF
VIFE next byte is manufacturer specific
126
1
83
VIFE L3
127
1
xx
VIFE status
128-133
6
xxxxxxxxxxxx
Apparent imported energy, L3
134
1
8E
DIF size, 12 digit BCD
135
1
40
DIFE, Unit 1
136
1
84
VIF for units kWh with resolution 0,01kWh
137
1
FF
VIFE next byte is manufacturer specific
138
1
81
VIFE L1
139
1
xx
VIFE status
140-145
6
xxxxxxxxxxxx
Active exported energy, L1
146
1
8E
DIF size, 12 digit BCD
147
1
40
DIFE, Unit 1
148
1
84
VIF for units kWh with resolution 0,01kWh
149
1
FF
VIFE next byte is manufacturer specific
