ABB A43

Communication with M-Bus
2CMC48001M0201 219 A43/A44
Revision: C User Manual
Byte No.
Size
Value
Description
150
1
82
VIFE L2
151
1
xx
VIFE status
152-157
6
xxxxxxxxxxxx
Active exported energy, L2
158
1
8E
DIF size, 12 digit BCD
159
1
40
DIFE, Unit 1
160
1
84
VIF for units kWh with resolution 0,01kWh
161
1
FF
VIFE next byte is manufacturer specific
162
1
83
VIFE L3
163
1
xx
VIFE status
164-169
6
xxxxxxxxxxxx
Active exported energy, L3
170
1
8E
DIF size, 12 digit BCD
171
1
C0
DIFE, Unit bit 0
172
1
40
DIFE, Unit bit 1, unit bit0-1-> unit 3
173
1
84
VIF for units kvarh with resolution 0,01 kvarh
174
1
FF
VIFE next byte is manufacturer specific
175
1
81
VIFE L1
176
1
xx
VIFE status
177-182
6
xxxxxxxxxxxx
Reactive exported energy, L1
183
1
8E
DIF size, 12 digit BCD
184
1
C0
DIFE, Unit bit 0
185
1
40
DIFE, Unit bit 1, unit bit0-1-> unit 3
186
1
84
VIF for units kvarh with resolution 0,01 kvarh
187
1
FF
VIFE next byte is manufacturer specific
188
1
82
VIFE L2
189
1
xx
VIFE status
190-195
6
xxxxxxxxxxxx
Reactive exported energy, L2
196
1
8E
DIF size, 12 digit BCD
197
1
C0
DIFE, Unit bit 0
198
1
40
DIFE, Unit bit 1, unit bit0-1-> unit 3
199
1
84
VIF for units kvarh with resolution 0,01 kvarh
200
1
FF
VIFE next byte is manufacturer specific
201
1
83
VIFE L3
202
1
xx
VIFE status
203-208
6
xxxxxxxxxxxx
Reactive exported energy, L3
209
1
8E
DIF size, 12 digit BCD
210
1
C0
DIFE, Unit bit 0
211
1
80
DIFE, Unit bit 1
212
1
40
DIFE, Unit bit 2, unit bit0-2-> unit 5
213
1
84
VIF for unit kVAh with resolution 0,01kVAh
214
1
FF
VIFE next byte is manufacturer specific
215
1
81
VIFE L1
