63
Analog Output 1 (ao1) Assignment Source
Select the source required to activate Analog Output 1.
See Rear Fold-out/ Table D – Analog Sources.
Analog Output 1 (ao1) Electrical High
The maximum current output required for the analog output.
[0.0 to 22.0mA]
Analog Output 1 (ao1) Electrical Low
The minimum current output required for the analog output.
[0.0 to 22.0mA]
Retransmission 1 Engineering High
The engineering range value at which maximum output is required.
[In engineering units]
Retransmission 1 Engineering Low
The engineering range value at which minimum output is required.
[In engineering units]
Continued…
4 CONFIGURATION MODE…
C02...C064.8.2 Analog Output 1
•1 If the output is assigned to a control output by the control type, the setting displayed cannot be changed – see
Section 4.2, Basic Configuration/ Control Output Type.
•2 Not applicable if analog output 1 is assigned to a control output.
tYP1
ANLG
NONE
AnI.A
100.0
r1.H
C.02
C.05
0.0
r1.L
C.06
20.0
AN1.H
C.03
4.0
AN1.L
C.04
AN2.A
NONE
•1
•2
•2
