ABB ControlMaster CM30 User Manual

ControlMaster CM30, CM50 and CMF310
Universal process controllers,
1
/4,
1
/2 DIN and fieldmount 4 Installation
8 IM/CM/ED–EN Rev. X
4.2 Dimensions
4.2.1 CM30 Controller
4.2.2 CM50 Controller
Dimensions in mm (in.)
Fig. 4.3 ControlMaster CM30 Dimensions
Dimensions in mm (in.)
Fig. 4.4 ControlMaster CM50 Dimensions
Controllers can be
close-stacked to
DIN 43835
97 (3.8)
97
(3.8)
121 (4.8)
141 (5.5)
91.8
(3.6)
20 (0.8)
92
(3.6)
+0.03
–0
+0.8
–0
9 (3.6)
14 (0.55)
30 (1.18)
+0.8
–0
+0.03
–0
Controllers can
be close-stacked
to DIN 43835
144
(5.6)
123 (4.9)
146 (5.7)
137.8
(5.4)
23 (0.9)
138
(5.4)
30 (1.18)
14 (0.55)
(+0.04
–0)
+1.0
–0
(+0.03
–0)
+0.7
–0
68
(2.7)
76 (3.0)
