ControlMaster CM30, CM50 and CMF310
Universal process controllers,
1
/4,
1
/2 DIN and fieldmount 3 Display Overview
IM/CM/ED–EN Rev. X 5
3 Display Overview
The ControlMaster displays and icons are shown in Fig. 3.1:
Fig. 3.1 ControlMaster Displays and Icons
PV Value
Bargraph
Setpoint Value
Icons
Access
Level
Manual
Mode
Local
Setpoint
Remote
Setpoint
Output Value
Auto
Mode
Operator Level
Menu
Process
Alarm
Autotune
Feedforward
Totalizer
Running
Adjust–
Indicates which
value is adjusted by
the /
keys
Totalizer
Stopped
Adaptive
Gain
CM30 and CMF310 Displays
CM50 Display
Profile
Setpoint
