ControlMaster CM30, CM50 and CMF310
Universal process controllers,
1
/4,
1
/2 DIN and fieldmount 9 PC Configuration
IM/CM/ED–EN Rev. X 97
9 PC Configuration
In addition to local configuration via the front panel keys, the controller can be configured from a PC via the
infrared port using the ConfigPilot PC configuration software. The controller's infrared port is activated
when accessing the following page in the Advanced level:
Advanced>Device Setup>IrDA Configuration>Connect
Fig. 9.1 PC Configuration via Infrared Port
Infrared Port on
CM30 and
CMF310
Controllers
Infrared USB Adaptor
Infrared Port on
CM50 Controller
