ABB ControlMaster CM30 User Manual

ControlMaster CM30, CM50 and CMF310
Universal process controllers,
1
/4,
1
/2 DIN and fieldmount 4 Installation
10 IM/CM/ED–EN Rev. X
Dimensions in mm (in.)
Fig. 4.6 ControlMaster CMF310 Pipe-mount Option
213 (8.38)
194
(7.64)
Cable Gland Kit (Optional)
Pipe Diameters:
Max. 62 (2.44) / min. 45 (1.77)
Pipe-mount Kit
(Optional – CM40/0700)
Vertical Configuration
Horizontal Configuration
170 (6.70)
98 (3.85)
66 (2.6)
