ABB EQmatic
Device technology
10 2CDC512090D0202 | QA/S x.yy.1
Operating and display elements
ON LED (green)
Ready indicator
LAN/LINK LED (yellow)
Network connection/telegram traffic indicator
M-Bus LED (yellow)
M-Bus ready indicator
Reset button
Rear label carrier
Degree of protection
IP 20
According to EN 60529
Protection class
II
According to EN 61140
Isolation category
Overvoltage category
Pollution degree
III according to EN 60664-1
2 according to EN 60664-1
Temperature range
Operation
-5 °C…+45 °C
Storage
-25 °C…+55 °C
Transport
-25 °C…+70 °C
Environmental conditions
Humidity
Maximum 93%, moisture condensation is to
be excluded
Atmospheric pressure
Atmosphere up to 2,000 m
Design
Modular DIN rail component (MDRC)
Pro
M
design
Dimensions
90 x 72 x 64 mm (H x W x D)
Installation width/installation depth
4 modules with 18 mm/68 mm
Mounting
On 35 mm mounting rail
According to DIN EN 60 715
Mounting position
Any
Weight
Approx. 0.15 kg
Housing, color
Plastic, light gray
Halogen-free
Flammability V-0 as per UL94
CE marking
In accordance with the EMC and
Low Voltage Directives
