2.2 Device technology QA/S 4.xx.1 Energy Analyzer, Modbus
The Energy Analyzers, Modbus RTU
QA/S 4.xx.1, are modular DIN rail
components (MDRC) in Pro M design for
installation in distribution boards on a
35 mm mounting rail.
They are compact, web-based
standalone devices for energy
management applications in Modbus
RTU networks. They log, store, display
and analyze consumption data for up to
16 or 64 electricity, gas, water or heat
meters. They automatically detect ABB A
and B series meters during
commissioning. Device access is via web
browser.
Various interfaces are available for
further processing the data.
The user interface provides graphic
analysis features such as
• A configurable dashboard
• Display and evaluation of historical
data
• Analysis of instantaneous values
• Period comparison (before/after)
• Comparison of up to 5 consumers
• Display of cost/consumption figures
by consumer groups
Technical data
Energy Analyzer, Modbus
Modbus RTU master
According to DIN EN 13757-2
Max. number of Modbus RTU slaves QA/S 4.16.1 QA/S 4.64.1
16 64
Supply
Operating voltage U
s
100 – 240 V AC, 50/60 Hz
Power consumption at 230 V AC
< 10 W
Current consumption at 230 V AC
< 50 mA
Device power loss at 230 V AC
< 3 W at 230 V AC
Web server and device properties
Simultaneous access to web server Max. 10 users
Retrieval/storage of meter data
Every 5 minutes
IP security HTTPS, SSL
Data export JPG, PNG, CSV, XLSX, PDF, JSON
Data transfer
Modbus-TCP, REST API, web sockets
Report
FTP or e-mail
Storage capacity with up to 64 Modbus
slaves/devices
Min. 3 years
Network
Ethernet 10/100 Mb
Connections
Operating voltage and RS-485/Modbus
Screw terminal, universal head
0.2…4 mm² stranded
0.2…6 mm² solid core
Tightening torque
Maximum 0.6 Nm
LAN RJ45 connector for 10/100BaseT
IEEE 802.3 networks, autosensing
2CDC07103xF0017
