ABB EQmatic
Commissioning
32 2CDC512090D0202 | QA/S x.yy.1
3.2.1.1 Meter configuration (QA/S 3.xx.1 Energy Analyzer, M-Bus)
ABB EQ A4x and B2x meters are automatically detected after a scan and do not need to be
configured. Available data points, which depend on the meter type, are listed in the data points list.
If an M-Bus device is shown as Not Configured or Unknown after the scan, you must configure the
device and its data points. For this purpose, click the Edit button for the relevant device in All
meters.
Note
An M-Bus device is considered configured (status OK) as soon as one of the data points for
consumption has been configured.
Electricity meter: Active energy (kWh)
Active power (W)
Water meter: Volume (m³)
Gas meter: Volume (m³)
Heat meter: Active energy (kWh)
