ABB EQmatic
Commissioning
44 2CDC512090D0202 | QA/S x.yy.1
Configure the required data points in the form according to the manufacturer's description and save
the settings.
Note
For correct operation, as a minimum the data point for the product name and one of the following data
points for consumption must be configured
Electricity meter: Active energy (kWh)
Active power (W)
Water meter: Volume (m³)
Gas meter: Volume (m³)
Heat meter: Active energy (kWh)
4. Scan
After a successful scan, meter models configured as in the previous instructions are detected and
marked in the table with the status OK. The system is now ready for operation.
Should one of the following status messages appear in the table after the scan, the meter model or
register mapping with data points must be configured, corrected or added.
NOT CONFIGURED
Meter model is linked to register mapping, however at least 1 data point is not configured.
Configure.
NOT IDENTIFIED
• Register mapping is defined, however meter model unknown or
• Register mapping is defined, however it is linked to the wrong meter model.
DISCONNECTED
• Device not connected to bus
• Data points incorrectly configured in the register mapping or not available in the device
• Collision: Address conflict. Devices with same primary address and speed.
OK
Meter detected, configured and connected. System ready for operation
