ABB Switzerland Ltd HE
Archive No.: Rev. Date:
Factory Settings and Routine Tests
-
Responsible Department: Prepared and tested Approved: Distribution: Lang.: Page:
PTUKT
- EN 1/1
Valid for: Derived from: Replaces: Classification-No.: Document No. / File:
- - -
We reserve all rights in this document and in the information contained therein. Reproduction, use or disclosure to
PLC Equipment
ETL600
Factory Settings and Routine Tests
Part of Programming and Testing Instructions 1KHW001493
Project ……………………………………………………
ABB Order No.: ……………………………………………………
Station ……………………………………………………
Frequency TX = ……… kHz RX = ……… kHz
Direction ……………………………………………………
Contents:
ETL600 System Settings A1 to A4
ETL600 System Test Report B1 to B11
HMI600 Printout of Configuration
The tuning of the equipment is in accordance with the following instructions:
Compatibility Requirements for ETL600 1KHW001490-EN
Tuning Instructions for Rx RF Filter P4RX 1KHW001491-EN
Tuning Instructions for Tx RF Filter E5TX 1KHW001492-EN
Instruction for Changing the Input Voltage of B5LC 1KHL015788-EN
APLC Channel Equalization for ETL600 1KHW001494-EN
Firmware Download for ETL600 1KHW001496-EN
Technical Data ETL600 1KHW001498-EN
third parties without express authority is strictly forbidden. © ABB Switzerland Ltd
Form 1KHW001493-EN Rev. A
