38 Start-up

FPBA-01 configuration parameters – group A (group 1)

Note: The actual parameter group number depends on the drive

type. Group A (group 1) corresponds to:

• parameter group 51 in ACSM1, ACS355, ACS380, ACS580,

ACS850 and ACQ810

• parameter group 51 in ACS880 and ACS880-M04 if the

adapter is installed as fieldbus adapter A or group 54 if the

adapter is installed as fieldbus adapter B.

No. Name/Value Description Default

01 FBA type Read-only. Shows the fieldbus

adapter type as detected by the

drive. The value cannot be

adjusted by the user.

If the value is 0 = None, the

communication between the drive

and the module has not been

established.

1 =

Profibus_

02 Node address Each device on the PROFIBUS

network must have a unique node

number. This parameter defines a

node number for the drive the

module is connected to.

Recommended node numbers are

3 to 125 inclusive.

0…126 Node number

03 Baud rate Read-only. Indicates the detected

communication speed in kbit/s.

Default value is 0 if there is no

connection.

1500

12000 12 Mbit/s

6000 6 Mbit/s

3000 3 Mbit/s

1500 1.5 Mbit/s

500 500 kbit/s

187 187.5 kbit/s
