Start-up 39
93 93.75 kbit/s
45 45.45 kbit/s
19 19.2 kbit/s
9 9.6 kbit/s
04 MSG type Read-only. Indicates the telegram
type selected for PROFIBUS
communication. The adapter
module automatically detects the
telegram type used.
For more information on the
supported PPO message types,
see section PPO types on page
135.
If standard telegrams (ST) are
used, parameter 05 Profile is
automatically set.
1 = PPO1
1 = PPO1 PPO1 selected
2 = PPO2 PPO2 selected
3 = PPO3 PPO3 selected
4 = PPO4 PPO4 selected
5 = PPO5 PPO5 selected
6 = PPO6 PPO6 selected
7 = ST1 ST1 selected
8 = ST2 ST2 selected. Only supported with
ACSM1.
9 = PPO7 PPO7 selected
10 = PPO8 PPO8 selected
20 = ST20 Standard telegram 20.
Visible only in VIK-NAMUR
emulation mode.
No. Name/Value Description Default
