46 Start-up
FPBA-01 configuration parameters – group B (group 2)
Note: The actual parameter group number depends on the drive
type. Group B (group 2) corresponds to:
• parameter group 55 in ACS355
• parameter group 53 in ACSM1, ACS380, ACS580, ACS850,
ACQ580, and ACQ810
• parameter group 53 in ACS880 and ACS880-M04 if the
adapter is installed as fieldbus adapter A or group 56 if the
adapter is installed as fieldbus adapter B.
No.
1)
Name/Value Description Default
01 FBA data out 1
(master to
drive)
Selects the resolution of control word
(16 bit or 32 bit) received by the drive.
1 or
11
2)
1 = CW 16bit Control word (16 bits)
11 = CW 32bit Control word (32 bits)
02 FBA data out 2 Selects data word 1 received by the
drive over the PROFIBUS network.
The content is defined by a decimal
number in the range of 0 to 9999 as
follows:
See also Virtual address allocation
with ACSM1 on page 50.
0 or
24
4)
0 = None Not used
1 = CW 16bit Control word (16 bits)
3)
2 = Ref1 16bit Reference REF1 (16 bits)
3)
3 = Ref2 16bit Reference REF2 (16 bits)
3)
11 = CW 32bit Control word (32 bits)
12 = Ref1 32bit Reference REF1 (32 bits)
0 Not used
1…99 Virtual address area of
drive control
101…9999 Parameter area of the
drive
