Start-up 47
13 = Ref2 32bit Reference REF2 (32 bits)
21 = CW2 16bit Control word 2 (16 bits)
101…9999 Parameter index with format xxyy,
where
• xx is the parameter group number
(1…99)
• yy is the parameter number index
within that group (01…99).
Other Path to parameter area selection.
03…
12
FBA data out 3
…
FBA data
out12
See parameter 01 FBA data out 1.0
1)
The number of parameters in this group may vary by drive type and drive
firmware.
2)
11 (CW 32bit) is the default setting if the Transparent 32 profile is used.
3)
With an ACS355 drive, Control word and REF 1 are always fixed to
virtual addresses 1 and 2 respectively. If REF2 is used, its virtual
address is always 3.
4)
2 (Ref1 16bit) is a fixed setting with an ACS355 drive.
