48 Start-up
FPBA-01 configuration parameters – group C (group 3)
Note: The actual parameter group number depends on the drive
type. Group C (group 3) corresponds to:
• parameter group 54 in ACS355
• parameter group 52 in ACSM1, ACS380, ACS580, ACS850,
ACQ580, and ACQ810
• parameter group 52 in ACS880 and ACS880-M04 if the
adapter is installed as fieldbus adapter A or group 55 if the
adapter is installed as fieldbus adapter B.
No.
1)
Name/Value Description Default
01 FBA data in 1
(drive to master)
Selects the resolution of status word
(16 bit or 32 bit) sent by the drive.
4 or
14
2)
4 = SW 16bit Status word (16 bits)
14 = SW 32bit Status word (32 bits)
02 FBA data in 2
(drive to master)
Selects data word 1 sent by the drive
over the PROFIBUS network. The
content is defined by a decimal
number in the range of 0 to 9999 as
follows:
See also Virtual address allocation
with ACSM1 on page 50.
0 or 5
3)
0 = None Not used
4 = SW 16bit Status word (16 bits)
5 = Act1 16bit Actual value ACT1 (16 bits)
6 = Act2 16bit Actual value ACT2 (16 bits)
14 = SW 32bit Status word (32 bits)
15 = Act1 32bit Actual value ACT1 (32 bits)
16 = Act2 32bit Actual value ACT2 (32 bits)
0 Not used
1…99 Virtual address area
of drive control
101…9999 Parameter area of the
drive
